3 Wheel Rear Drive Electric Counterbalanced Forklift Truck

24V rear-wheel drive provides smooth acceleration and excellent travel, torque and lifting performance. This is combined with regenerative braking to deliver efficient load handling.
AC motor technology on traction and hoist allows the truck to work more reliably for longer periods, significantly reducing downtime. The tight, class-leading turning circle allows the 1250kg model to operate faster in aisle widths of just 3,053mm.

The operator compartment features a standard full suspension seat with 80mm suspension travel. This helps provide unrivalled operator comfort and a smooth ride, delivering low vibration levels from 0.3-0.5m/s2, reducing the chance of back problems. A class leading low noise level of 59dB(A) reduces the stress on operators making them more productive for longer by ensuring that they are comfortable at all times.

The truck intelligent design delivers the right balance (e-Balance) of performance, manoeuvrability and battery shift life, which is matched to the application, providing increased productivity at less cost.

The eLo (Energy-Low) performance setting reduces energy costs, delivering the lowest energy consumption of 3.9kWh/h (1.3t) and 4.0 kW/h (1.5t) on the VDI 2198 test (45 cycles).

The VSM delivers diagnostic data to the dash display, enabling operators to anticipate maintenance needs and quickly carry out fault diagnosis.

Virtually maintenance-free components such as the truck’s AC motors mean a full service check isn’t required until 1,000 hours of use. The truck is fully serviceable without having to remove the battery, while the motor, pump, controller and oil tank are all easily accessible.
