Container Handlers

Empty Container Handler

RELIABLE AND FAST CONTAINER HANDLING

Models
H180-230XD-EC/D
Capacity
8000-11000kg

Designed for use in the ever growing, fast paced container industry, where every yard must bring down the cost per box moved to stay competitive.

  • Single and double handling spreaders
  • Heavy-duty productivity
  • Serviceability
  • Optimized powertrain
  • Ergonomic cab
Downloads
Industry Sector

- Ports and Intermodal / Container Yards
- Empty Container Handling

Ask the Experts

Interested in more information on this truck? Our solutions team is available to discuss your specific application and how this product can meet your needs.

Start a Quote

Reliability in container handling

Stack up to 9 high

Single and double handling spreaders

A comprehensive selection of single and double handling spreaders are available, featuring vertical twistlocks or hook & side clamps, to suit your specific application. These spreaders allow
operations to handle most common types of containers including ISO, WTP and domestic containers.

Heavy-duty productivity

Hyster® H180-230XD-EC/D container handling trucks deliver high productivity with 4-mode average speeds of 107 ft/min (0.54 m/s), competitive in the industry at rated laden container handling capacities.

For optimal performance and durability, the variable lap mast features:

  • significantly lower load roller forces
  • less mast deflection
  • higher torsional rigidity
  • heavy duty 2 chain system with large diameter sheaves

This design enhances structural strength, contributing to lower costs and reducing downtime.

Serviceability

Hyster trucks have been designed with the service technician in mind. Easy access to the engine, hydraulics and other major components are enabled with a large hinged hood and lift off front covers. The tip back cabin provides ample service access to components located under the cabin.

  • Broad, slip resistant running boards
  • Optional utility toolbox and storage compartment
  • The hydraulic oil tank features a sight glass and magnetic drain plugs for ease of maintenance
  • Clean hydraulic hose and electrical harness routing and clamping
Optimized powertrain

The Tier 4 Final Cummins QSB 6-cylinder diesel engine delivers 231 peak HP and 770 lb-ft of maximum torque, featuring cooled exhaust gas recirculation (EGR) technology with selective catalytic reduction (SCR) and an integrated diesel exhaust fluid (DEF) delivery system.

Innovative selectable ECO performance modes, plus the 5-speed transmission and variable displacement pumps, offer excellent fuel economy.

On-demand hydraulics keep oil temperature lower to protect hydraulic components.

Ergonomic cab

The ergonomically designed high visibility cab puts greater productivity within easy reach. Equipped with an armored glass top window, curved front and rear windows and steel doors with tempered glass, the operator cab provides excellent all-around visibility. Inside the cab there is more space with the largest entry area in the industry, more control with a full-color screen displaying performance data at the operator’s fingertips and more comfort with an exclusive lateral sliding seat, adjustable steering column and foot pedal, plus ergonomic controls.

Model Load Capacity Load Centre Lift Height Turning Radius Overall Width Weight Engine Transmission
H180XD-EC7 8000kg 1220mm 18768mm 6327mm 162mm 81377kg Cummins QSB 6.7L Diesel ZF - 5WG211
H190XD-ECD8 9000kg 1220mm 16322mm 6327mm 162mm 90065kg Cummins QSB 6.7L Diesel ZF - 5WG211
H200XD-ECD7 9000kg 1220mm 18922mm 6327mm 162mm 87012kg Cummins QSB 6.7L Diesel ZF - 5WG211
H200XD-EC8 9000kg 1220mm 21368mm 6327mm 171mm 91463kg Cummins QSB 6.7L Diesel ZF - 5WG211
H200XD-EC7 9000kg 1220mm 18768mm 6327mm 162mm 85755kg Cummins QSB 6.7L Diesel ZF - 5WG211
H230XD-ECD8 11000kg 1220mm 18922mm 6327mm 171mm 94461kg Cummins QSB 6.7L Diesel ZF - 5WG211
H210XD-ECD8 10000kg 1220mm 18922mm 6327mm 171mm 92343kg Cummins QSB 6.7L Diesel ZF - 5WG211
H230XD-ECD9 11000kg 1220mm 21522mm 6327mm 171mm 97440kg Cummins QSB 6.7L Diesel ZF - 5WG211
H180XD-EC6 8000kg 1220mm 16168mm 6327mm 162mm 78392kg Cummins QSB 6.7L Diesel ZF - 5WG211
