MEDIUM TO HEAVY-DUTY APPLICATIONS
With superior traction, the Hyster® tow tractor can pull loads of up to 7000kg.
- Durable and reliable
- Low cost of operation
- Fast travel speeds
- Intelligent on-board diagnostics
Durable and reliable
Low cost of operation
Fast travel speeds
Intelligent on-board diagnostics
The solid frame construction and reliable components ensure long-term reliability and durability.
The sturdy wraparound bumper plate protects the truck against impacts and damage and minimises repair costs.
Protected electronics, including the enclosed AC traction motor, sealed combi-controller (with IP65 rating), sealed electrical connectors and hall effect sensors and switches ensure excellent reliability and reduced servicing costs for maximum productivity.
CAN bus technology provides reduced wiring complexity and easy access to components. The tractor’s solid frame construction also ensures long-term reliability and durability.
Advanced control features, such as adjustable performance settings allow the truck to be tailored to the needs of the application, reducing energy consumption.
Regenerative braking reduces use of service brake and dissipates heat of traction motor, ensuring the longer life of key components.
With a maximum travel speed up to 13km/h, travelling time is reduced on long runs between docking and picking areas.
Acceleration, travel and braking speeds can be adjusted by a service engineer to the unique needs of the application via the console.
Effortless electrical steering and automatic speed reduction on cornering also ensures excellent control and high productivity.
Scooter control and electric steering reduces the arm movement required to change direction, keeping the driver within the truck footprint at all times. This provides added protection and reduces operator fatigue resulting in increased productivity.
The platform sensor, which detects when the operator is on board, covers the entire platform floor, which along with the high, soft touch, back rest, allows operators to locate the most comfortable driving position.
The wide and long operator platform provides increased comfort allowing easier passage through to optimise picking on both sides of the truck.
A foot controlled lifting platform option facilitates up to second level picking and limits the amount of reaching the operator has to do from rack to pallet, reducing operator fatigue.
The truck’s low maintenance AC traction motor with built-in thermal protection is fully enclosed for protection against damage and debris, minimising service downtime.
CANbus system and diagnostic control is monitored via the console or a single plug-point plus fault codes can be displayed on the console for easy service identification.
A one-piece hood provides easy access to key components and the AC motor cover is easily removed by two screws to provide full access to all the main components.
|Model||Load Capacity||Turning Radius||Battery Capacity||Overall Width|
|LO5.0T||5000kg||1434mm||24V / 425-600Ah(V/Ah)||31.3mm|
|LO5.0T (robot)||5000kg||1434mm||24V / 425-600Ah(V/Ah)||31.3mm|
|LO7.0T||7000kg||1434mm||24V / 425-600Ah(V/Ah)||31.3mm|
|LO7.0T (robot)||7000kg||1434mm||24V / 425-600Ah(V/Ah)||31.3mm|
