4-Wheel Electric Counterbalanced

INTEGRATED LITHIUM-ION 4-WHEEL PNEUMATIC TIRE FORKLIFT

Models
J30-70UTL
Capacity
3000-7000lbs

The cost-effective 4-wheel J30-70UTL is equipped with lithium-ion battery power designed into the forklift direct from the factory.

  • Integrated Lithium-ion Battery Power
  • Comfortable Operation
  • Low Cost of Ownership
  • Robust Components
Industry Sector

- 3PL & Warehousing
- Agriculture
- Auto Parts Distribution
- Beverage
- Chemicals & Plastics
- Cold & Frozen Foods
- Food Distribution
- Food Processing
- Health & Pharma
- Retail & E-Commerce (DC/Fulfillment)
- Trucking

Start a quote

Interested in more information on this lift truck? Our solutions team is available to discuss your specific application and how this product can meet your needs.

Start a quote

POWER AND PERFORMANCE WITH LOW TCO

Integrated Lithium-ion Battery Power

Hyster UTL models are equipped with a maintenance-free integrated lithium-ion battery with charge port that is designed into the forklift direct from the factory. AC traction and lifting motors with electronic control as well as maintenance-free oil-immersed brakes and a regenerative braking system provide for smooth performance. Multiple performance modes are selectable through the dash display.

Comfortable

Features a low step to enter the operator compartment, wide views through the mast and ample foot space. Hydraulic power steering, adjustable steering column and a full suspension seat with lumbar support offers added comfort.



Low Cost of Ownership

Maintenance costs and requirements are reduced by implementing readily available, cost effective replacement parts. Easy service access to the controllers and drivetrain helps minimize service time.

Robust Components

The use of high quality and robust components within the UT series delivers a reliable operation with limited wear and tear. Cylinders with hard chrome rods reduce seal wear for long life. A full-flow, low pressure filter on the return line keeps the hydraulic oil clean, which helps to minimize seal and pump wear. In addition, this keeps the control valve in good condition, leading to low service costs.

Model Load Capacity Load Center Lift Height Turning Radius Battery Capacity Voltage Weight
J30UT 3000lbs 24in 119.4 77.4 Lead acid or thin plate pure lead 6505
J35UTL 3500lbs 24in 119.4 77.4 Lead acid or thin plate pure lead 7120
J35UT 3500lbs 24in 119.4 77.4 Lead acid or thin plate pure lead 7120
J40UT 4000lbs 24in 119.6 81.9 Lead acid or thin plate pure lead 8665
J50UTL 5000lbs 24in 119.6 81.9 Lead acid or thin plate pure lead 9040
J70UT 7000lbs 24in 120.0 94.7 Lead acid or thin plate pure lead 11905
