Internal Combustion Forklift Pneumatic Tire
DURABLE AND RELIABLE OUTDOOR FORKLIFT
- Models
- H170-190FT
- Capacity
- 17000-19000lbs
Compact strength and proven performance for applications where size matters.
- Auto Deceleration System (ADS)
- Controlled rollback on ramp
- Throttle response management
- Hassle-free hydraulic systems
- Operator-friendly design
outstanding reliability and low cost of operation
The heavy duty industrial use engine comes with a cast iron cylinder block and no HT (high tension) wires, distributor caps or rotors.
Performance optimization developments are included such as cooling on demand, load sensing hydraulics (power on demand), RPM management and alternate engine idle speed to help further reduce the total fuel consumption in most applications.
ECO-eLo performance mode reduces energy consumption by up to 15% compared with previous generation engines.
The transmission controls the rate of decent on a ramp when the brake and throttle pedal are released. This provides maximum control on a grade and increases operator productivity.
This feature allows the operator to manage their travel speed, according to the position of their foot on the accelerator pedal.
Hydraulic systems such as the leak-free O-ring face seal fittings reduce leaks for enhanced reliability. Non-mechanical, Hall-Effect sensors and switches have also been fitted which are designed to outlast the life of the truck.
Operator space is optimized, thanks to the modern overhead guard design and significantly expanded floor space. The truck also has an easy to use three-point entry design with a low step height.
Model | Load Capacity | Load Center | Lift Height | Turning Radius | Overall Width | Weight | Engine Type | Transmission |
---|---|---|---|---|---|---|---|---|
H170FT | 17000lbs | 24in | 258 | 149 | 88 | 24824 | Kubota 3.8L Diesel | DuraMatch™ 3, 3-speed |
H175FT | 17500lbs | 36in | 258 | 149 | 88 | 26782 | Kubota 3.8L Diesel | DuraMatch™ 3, 3-speed |
H170FTS | 17000lbs | 24in | 258 | 149 | 88 | 24824 | Kubota 3.8L Diesel | DuraMatch™ 3, 3-speed |
H190FT | 19000lbs | 24in | 258 | 149 | 88 | 25857 | Kubota 3.8L Diesel | DuraMatch™ 3, 3-speed |
