4 Wheel Electric Forklift Truck Pneumatic Tire
HIGH-CAPACITY ELECTRIC FORKLIFT
The Hyster® J155-190XNL sit-down counterbalanced forklift powered by integrated lithium-ion technology is designed to satisfy a need for a zero emission alternative in a high capacity range for both indoor and outdoor operation. Integrated lithium-ion power is a suitable solution for heavy-duty applications, providing ICE-like performance with zero emissions.
- Energy efficient
- Ergonomic operator compartment
- Low cost of operation
- J155-170XNSL models
GOOD DESIGN AWARD
The J155-190XNL series earned the top spot in the lift trucks and accessories category as a high-performance, zero emission alternative for heavy-duty, higher-capacity applications that have traditionally relied on internal combustion engines.
The battery fully charges from lift lock-out (12% state of charge) in less than 90 minutes with the required 50kW charger, and once charged, it stays over 90% efficient throughout operation.
The strategic design that incorporates the integrated lithium-ion battery creates more space in the operator compartment, maximizing comfort and convenience to help propel productivity.
- Extra space allows the option for Air-Ride Seats for a smoother ride and operator comfort.
- With no ICE engine running, truck noise levels are much quieter and there are no emissions
- Low intermediate step height for easy three-point entry and exit.
- Highly adjustable steering column and ergonomically positioned operators seat with integrated armrest incorporating mini-levers for hydraulic control and other key functions.
- The dash display transmits continuous feedback to the operator of the truck’s status and is positioned for optimum visibility.
Lithium-ion power is an ideal solution for heavy-duty applications due to the sealed battery requiring no battery maintenance, faster charging, and longer overall battery cycle life when compared to typical lead-acid batteries.
If you are operating separate indoor and outdoor trucks, utilizing the J155-190XNL can cut your fleet in half. Why? Because this truck is designed to work in both indoor and outdoor applications.
J155-170XNSL truck models with a short counterweight are available to give extra maneuverability in applications where space is in short supply. The shortened counterweight and Turn Assist System helps provide an outstanding minimum outside turning radius and right angle stack.
|Model||Load Capacity||Load Center||Battery Capacity Voltage|
|J155XNL||15500lbs||24in||350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet|
|J170XNL||17000lbs||24in||350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet|
|J175XNL||17500lbs||36in||350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet|
|J190XNL||19000lbs||24in||350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet|
Support throughout the lift truck life cycle
Knowledgeable, reliable dealers make all the difference
When it comes to collaborating with a lift truck dealer, you can’t settle – you need dealers wholly focused on your success. When you purchase equipment or technology solutions from Yale Lift Truck Technologies, you gain access to our independent dealer network. “Independent” means our dealers are not constrained by factory ownership or corporate red tape.
Our dealers are entirely focused on fulfilling your needs
- A seamless experience, from order to factory to ongoing support
- Effective recommendations and responsive support, from parts, maintenance and
emergency services to fleet management, rental trucks and operator training.
- Expertise and guidance on special features and allied products and services for your
warehouse, like racking, guarding and safety equipment.
- Assistance with financing options.
The GSA creates a centralized location for the federal government, offering products, services, and facilities needed for federal agencies to serve the public. As a GSA certified company, Hyster supports the GSA’s mission to provide innovative solutions for federal agencies with cost-effective and high-quality products. You can also find more information on the General Services Administration at www.gsaadvantage.gov
WIRELESS ASSET MANAGEMENT
Hyster Tracker provides true wireless fleet management, can drive fleet efficiency, improves operator performance, reduces your carbon footprint and lowers your overall material handling costs.
POWER YOUR POSSIBILITIES
HYSTER POWER MATCH
Not all power is the same. Learn how a better-matched power source could make a difference in your operations.
The forklift is only part of the solution
Hyster knows that a tough lift truck is even better when it comes with a strong partner to meet your unique needs.
Order Forklift Parts Online
The Quality Parts Your Truck Needs
Request access to tools to help you find the right part, access technical information and shop from the convenience of your home, office or shop.
Hyster Fleet Management
We Get Fleet Done
If you have a fleet, whether it’s forklifts or other types of equipment, we can help you manage it with the just-right program tailored to meet your needs.
